Multi-purpose furnace SHQB-10 – Product Overview

The SHQB-10 Multi-Purpose Furnace is a compact, reliable, and energy-efficient Heat treatment furnace designed to perform a variety of thermal processes. With its precise temperature control and durable construction, this model is well-suited for small-scale production, research laboratories, and quality control environments.

Key Features:

• Wide Heat Treatment Capability: Supports multiple processes including annealing, tempering, hardening, stress relieving, and sintering.

• Compact Design: 10-liter chamber capacity is ideal for small batches, lab work, and prototyping.

• High Temperature Performance: Operates at temperatures up to 1,100°C (customizable up to 1,200°C).

• Accurate Temperature Control: Equipped with a digital PID temperature controller for stable and precise thermal regulation.

• Uniform Heating: Designed with optimized heating elements to ensure consistent temperature distribution across the chamber.

• Durable and Efficient: Constructed with high-quality heat-resistant materials and efficient thermal insulation for long-term use and reduced energy consumption.

Technical Specifications:

• Model: SHQB-10

• Chamber Volume: 10 Liters

• Max Operating Temperature: 1,100–1,200°C (based on configuration)

• Power Supply: 380V / 50Hz or customized

• Temperature Control Accuracy: ±1°C

• Heating Method: Electric resistance

Applications:

• Heat treatment of tools and small metal parts

• Laboratory material testing and thermal research

• Sintering of ceramics and powder metallurgy samples

• Pre-production trials and R&D projects

Optional Features:

• Controlled atmosphere system (inert or reactive gas)

• Programmable temperature profiles

• Data logging and remote monitoring

• Over-temperature protection and safety interlocks
